DBS (Dynamic Block System)

It is a device that operates as a differential. When active, the vehicle, when steering, leaves no trace on the ground (ideal for green care). Particularly suitable for use on uneven surfaces.

Electronic Throttle Control

ETC – Electronic Throttle Control

HI-Flow

Additional pump that increases the outlets oil flow.

Hydraulic multiconnector

It is a innovative coupling system for front attachments that allow the connection of the hydraulic lines in a few seconds without stress.

Hydraulic oil cooler

System for cooling the hydraulic circuit oil

LCD graphic display with programmed service

LCD graphic display with programmed service (tachometer, hour meter, fuel gauge, maintenance light, light indicator and other 14 indicators)

Multi-disk parking brake

Multiple Disc Brakes spring loaded and hydraulically released.

Radial Piston Wheel motor

High performance, high torque cam-lobe radial-piston hydraulic motors.

ROPS-FOPS Level I

The ROPS (Rollover Protection System) is a system or structure intended to protect the operator from injuries caused by machine overturns or rollovers.
The FOPS (Falling Object Protection System) is tested and certified in accordance with ISO 3449 and protects the operator against falling objects. In some countries and for some works the FOPS may be mandatory. Please consult your local MultiOne distributor.

Self-levelling double-H telescopic boom

It conveys extreme strength and high visibility of the load, allowing for a greater lifting capacity.

MultiOne’s telescopic boom:

• it has a significant extension in length, which allows to reach the farthest points and also not easily accessible areas, as well as great dumping heights and outreach
• it has special anti-friction pads, which ensure operation, durability and lack of maintenance
• it assures an excellent front visibility at any time, even while moving and lifting
• thanks to the self-levelling, it is ideal for lifting heavy loads since it keeps the load leveled to the ground, preventing the operator from continuously correcting the position with the joystick.

Unbreakable Body Panels

The resistance and flexibility of the compound used on the new body cover let the panel absorb shocks, deforms and go back to original shape.

4WD hydrostatic Direct Drive motors

4WD hydrostatic Direct Drive motors, proportional servo

2 speed

Electro-hydraulic speed regulation.

2 front working light

2 front working light to illuminate the working area

Additional working lights, LED

Additional working lights, LED, set of 3

Aux hydraulic outlets

Additional hydraulic outlets (front and/or rear).

Attachment coupling plate for rear mounting

It is used to assemble attachments on the rear of the machine.

Automatic locking/unloacking plate

On the automatic attachment plate the locking pins move hydraulically and
are operated from cockpit.
This way the driver can stay on the seat when coupling and disconnecting
non-hydraulic attachments.

Backup warning beeper

It help keep everyone safer during MultiOne machine operation

Beacon light

Beacon light ensures more visibility and safety

Driver area cover

Covers the machine interior, protects against rain, snow, etc.

Engine block heater

It is an ideal device for cold temperatures.
The system keeps the engine at an optimal temperature for easy starting with very cold climates.

Flat face coupling kit

Adaptor to be put on the multiconnector, in order to connect standard flat face connections

Floating boom valve

It allows the mounted attachments to follow the contours of the land perfectly. Ideal for applications in agriculture and in the care of the green areas.

Fully enclosed cab (glass)

This is the best insulation system for the driver to protect him from cold, wind, rain, and snow.
Easy access thanks to the large door and the compass glass opening.

GPS Tracker

Heating system

Three-way heating with adjustable air flows and temperature.

Left protection bar for operator

A side-protection bar that has been certified and awarded as a techincal safety innovating system. It is placed on the left side of the machine to protect the operator from falling out of the vehicle. It can be locked and unlocked very quickly thanks to a special mechanism.

Smart Cabin

The most competitive solution for the operator who wants to improve working conditions thanks to a light cabin which limits the discomfort created by weathering.

Rear bull bar

It protects the rear side of the machine in case of shocks. With side extensions
from 7 series on. Not compatible with rear weights, trailer coupling and rear
coupling plate.

Rear hydraulic outlets

They are used to mount on the rear side attachments that need hydraulic supply. The rear outlets are controlled by the control panel.

Rear side weights

Rear side weights are used to increase the lifting capacity of the machine. It’s possibile to mount them also with other rear weights mounted.
Two kit (80 kg per side, 160 kg total) can be mounted, screw is required.

Rear weights

Backweights are used to increase the lifting capacity of the machine. They are to be mounted on the rear of the machine.

Ride control

Ride control is a shock absorber system for the boom. When driving at high speed with a heavy load or heavy attachment, the boom starts to move up and down, making the driving bumpy. Ride control consists of an accumulator that absorbs and reduces boom movements and makes driving considerably smoother and more stable.

Skid tires

Snow chains

MultiOne snow chains improve traction on snow.

Tie down bracket on wheel hub

The tie down brackets mounted on wheel hub makes easier to tie down the machine on a trailer.

Torque divider

It acts on all four wheels simultaneously to attain maximum performance. Traction even on impossible grounds with mud or snow.

Tractor Tires

Trailer coupling

Rear tow hook with double connection: with tow ball (car type) or tow pin (agricultural type).

Turf tires

Warning and safety lights for road travel (w/mirrors)

Front and rear lights, brake lights, turning lights, beacon, mirrors. In certain countries this equipment enables road traffic registration – requirements vary in different countries.

Wheel spacer

Wheel spacer are used to make the machine wider and increase its stability

“2” Hitch receiver

Two type of trailer coupling: A) rear tow hook with double connection: with tow ball (car type) and tow pin (agricultural type). B) 2” Hitch receveir.

Not compatible with 2.3 EFI. Can be used also with rear weights.
