2 SERIES

Light & Powerful

Power 26,5 hp
Tipping load 700 kg – 1543 lbs
Lift height 1,6 m – 63 in

Find a DealerMore Info

The smallest and most economical articulated series of MultiOne.

This machine provides high performance on any surface.
The articulation system allows the operator to drive the machine with total comfort, even in narrow spaces.

The harmony of a compact performance and an innovative design makes the 2 Series the most competitive machines of their category, the best solution for DIY activity.

2 Series Plus:

  • Articulated frame
  • Compact dimensions
  • Quick starting

TECHNICAL DATA

serie 2 quote

EngineKOHLER Command Pro EFI ECV749
Power (Iso Gross)26,5 HP / 19.7 kW
FuelPetrol
TransmissionHydrostatic
Drive speed (max)15 km/h (9.3 mph)
Aux. hydraulic oil flow42 l/min (11.1 gal/min)
Max lifting height1,6 m (63 in)
Breakout force / 50 cm840 kg (1852 lbs)
Turning radius: inside/outside700 / 1698 mm (27.6 / 66.9 in)
Standard tires (Tractor profile)20×8.00-10
Weight710 kg (1570 lbs)
Tipping load (w/backweights)700 kg (1543 lbs)
Lifting capacity (straight and w/backweights)560 kg (1235 lbs)
Lifting capacity (fully articulated and w/backweights)450 kg (992 lbs)
CodeC951028
