TECHNICAL DATA

Multione 8.4Sk Mini Articulated Loadert Lift height

Model8.4S K Stage IIIA8.4S K Stage V
EngineKubota V1505, 4 cyl -1498 ccKubota V1505, 4 cyl -1498 cc
Emission StandardStage IIIAStage V – TIER 4 Final
Power (Iso Gross) / Torque37.5 HP / 97 Nm @ 2000 rpm26 HP / 93 Nm @ 1700 rpm
FuelDiesel Diesel
TransmissionHydrostatic OneDriveHydrostatic OneDrive
Drive speed (max)13 – 26 km/h (8 – 16 mph)11 – 22 km/h (6.8 – 13.6 mph)
Aux. hydraulic oil flow67 l/min (17.7 GPM)52 l/min (13.7 GPM)
Max lifting height2,98 m (117.3 in)2,98 m (117.3 in)
Breakout force / 50 cm1700 kg (3748 lbs)1700 kg (3748 lbs)
Turning radius: inside/outside825 / 2090 mm (32.5 / 82.3 in)825 / 2090 mm (32.5 / 82.3 in)
Standard tires (Tractor profile)26×12.00-12 ET-5026×12.00-12 ET-50
Weight1680 kg (3710 lbs)1680 kg (3710 lbs)
Max tipping load (w/backweights)1840 kg (4056 lbs)1840 kg (4056 lbs)
Lifting capacity (straight and w/backweights)1470 kg (3240 lbs)1470 kg (3240 lbs)
